Slim folding doors wrapping a garden corner of a brick extension

Thermal Break

73-65 Series Slim-Frame Folding Door

قطاع 65-73 العازل للحرارة — باب قابل للطي بإطار نحيف

Slim-frame folding: the 73-65 pairs narrow sightlines with full folding-and-sliding operation, so stacked-away panels read as a single line of bronze.

Product attributes المواصفات

Opening Method: Folding and sliding
Min Size: Door leaf height 2000 mm
Max Size: Door leaf height 3500 mm
Max Load: Single leaf 100 kg
Glass Specification: 5+27A+5 mm
Hardware Brand: Kerssenberg

Performance الأداء

U-Value (BTU/ft²·hr·°F): 0.229
Water Penetration (Pa): 260
Serviceability Limit State (SLS): 1680
Ultimate Limit State (ULS): 2520

Parameters obtained through AAMA / CSA / NAFS testing. The system structure can be adjusted to project requirements to achieve higher parameters.

Enquire about the 73·65 series Catalogue PDF
