96 Series Sliding with Screen
قطاع 96 — نوافذ وأبواب سحّاب وشبك
The everyday screened slider: uniform 1.3 mm profiles, insulating glass, and an integrated screen track — a dependable system for bedrooms, kitchens, and service openings.
Product attributes المواصفات
- Outer Frame Thickness
- 1.3 mm
- Window Panel Thickness
- 1.3 mm
- Door Panel Thickness
- 1.3 mm
- Width Limit
- 700 – 1000 mm
- Height Limit
- 1800 – 2400 mm
- Glass Specification
- Regular hollow insulating glass
- Hardware Brand
- KINLONG
Performance الأداء
- U-Value (BTU/ft²·hr·°F)
- 0.229
- Water Penetration (Pa)
- 260
- Serviceability Limit State (SLS)
- 1680
- Ultimate Limit State (ULS)
- 2520
Parameters obtained through AAMA / CSA / NAFS testing. The system structure can be adjusted to project requirements to achieve higher parameters.
